Our meters/iMG

household

eRS801
Ensor

high-precision measurement technology
Modular
CH Certified
Up to 120A continuous current
NFC

More about the product

Industrial and commercial

eRS301
Ensor

high-precision measurement technology
Measurement accuracy up to CI. 0.2S
CH Certified
Can be used from low to high voltage
Optional with Aron circuit

More about the product

medium voltage

eRS501
Ensor

high-precision measurement technology
Measurement accuracy up to Cl. 0.2S / 0.5 S for reactive current
19" slot
CH Certified

More about the product

communication

eRS801
Ensor

plug and play
Supports DLMS/COSEM or EN62056-21
minutes
DHCP or fixed IP
Amera DC 2.0

More about the product

communication

eRS301
Ensor

plug and play
Supports DLMS/COSEM or EN62056-21 protocol
DHCP or fixed IP

More about the product

accessories

I/O board for eRS801

plug and play
Up to 4 load control relays for local consumers
Two S0 pulse interfaces
M-Bus and wM-Bus

accessories

Blue2Box

Provides SCADA logs via P1/DSMR interface
Various interfaces P1 DSMR / M-Bus / RS-485 / LAN Ethernet / WAN Wi-Fi

accessories

Various accessories

antennas
Optical read head
cable

Frequently Asked Questions

What types of ensor meters are available?

ensor offers two types of electricity meters:

-eRS801 Direct-reading
-eRS301 Transducer meter

The eRS801 direct reading meter is available in various combinations. To select the right meter, three important questions should be clarified in advance:

Is a shutdown unit required?
Do you need G3 PLC communication?
Is the FAST version or drawbar clamps connection type desired?

What does FAST mean on Semax meters?

FAST is a term used to describe an electricity meter that has permanently integrated contact pins for the mains connection or plug-in terminals. This means that the pins no longer need to be aligned and fastened manually, which significantly reduces the time required for the rollout process. This in turn increases efficiency when replacing meters.

How long is the warranty on the meters and modules?

For everyone Semax electricity meters and communication modules, the legally prescribed warranty period of 2 years applies to all Semax electricity meters and communication modules. This warranty reliably covers material and manufacturing defects. Upon request, the warranty period can be extended for an additional charge. A warranty extension offers additional security. Please feel free to contact us if you would like a warranty extension or have further questions about the warranty.

Can a shutdown unit be retrofitted?

No, a breaker cannot be retrofitted.

What can be retrofitted on an eRS801 meter?

Communication module
M8-100 LTE
M8-110 Cat-M1
M8-340 Fiber optic
S8-520 bpl

I/O board with the following options
M-Bus (wired or wireless)
Relays (max. 4x 4 amps)
S0 interface (2 pieces)

How many amps (continuous power) can the eRS801 handle?

The eRS801 is designed for a continuous output of 100 amperes (100A) as standard. In its construction site meter version, the eRS801 is even designed for up to 120 amperes (120A).

How does the customer interface on the smart meter work and what can it be used for?

Information on technology, application, access authorization, and available standard products can be found on the official information platform for the smart meter customer interface at www.smart-metering-interface.ch.

Is there a wireless module that supports 4G (LTE)?

Yes, the M8-100 radio module is available for the eRS801 and the M3-100 radio module for the eRS301. The description of the communication modules can be found on our website under Meters > Communication.

Is there a broadband powerline module for the ensor meter?

Yes, for the ensor eRS801 was developed in collaboration with Swistec Systems AG. If you have ensor counters with G3-PLC communication, there may be restrictions on the use of the broadband powerline module. For a binding clarification, please contact Swistec: www.swistec.ch
